Description
The Sennheiser e 614 is a small-diaphragm super cardioid condenser microphone designed primarily for instrument recording and live sound reinforcement.
It is especially popular for drum overheads, hi-hats, percussion, acoustic guitar, strings, brass, and woodwinds because of its fast transient response and ability to handle high sound pressure levels.
Key Specifications
Type: Pre-polarized condenser microphone
Polar pattern: Super cardioid
Frequency response: 40 Hz – 20 kHz
Maximum SPL: 139 dB
Sensitivity: 3 mV/Pa
Output: 3-pin XLR
Phantom power: 12–52 V
Typical Uses
1. Drum overheads
2. Hi-hat microphone
3. Acoustic guitar
4. Piano
5. String instruments
6. Woodwinds and brass
7. Home recording studios
Pros
High SPL handling (great for loud sources)
Tight super cardioid pattern
Rugged metal construction
Affordable compared with many professional small-diaphragm condensers
